HCF Large format series fiber laser cutting machine

 Tip: Click on the picture to enlarge

Introduction & Application

        HCF single-table series fiber laser cutting machine integrates the latest generation of fiber laser source, combines with the

company's independent design of gantry-type numerical control machine tool, machine tool body adopts high-strength integral

welding machine body, after high temperature secondary annealing heat treatment process, large gantry milling machine precision

processing, good rigidity and stability; the beam uses a patented cast aluminium beam, with high strength and weight. It has the

advantages of light weight, good rigidity, high precision and importing high-speed gear and rack transmission, and mainly aims at

the fast and precise cutting of metal sheets under 50mm.

        Widely used in metal crafts, hardware products, precision machinery, automotive accessories, glasses, jewelry, name plates,

electronics, toys, advertising and other industries.


Technology Advantage

◆ Excellent light beam quality: smaller focus spot, higher efficiency and better processing quality;

◆ Extremely high cutting speed: 2-3 times the same power CO2 laser cutting machine;

◆ Extremely high stability: it adopts world's top imported fiber laser source , stable performance, the life of key components can reach

100,000 hours;

◆ Extremely high electricity-optic conversion efficiency:  fiber laser cutting machine is three times higher than CO2 laser cutting machine, energy saving and environmental protection;

◆ Low cost: the power consumption of the whole machine is only 20-30% of the same type of CO2 laser cutting machine;

◆ Low maintenance cost: no laser working gas; optical fiber transmission, without mirror, can save a lot of maintenance costs;

◆ Convenient operation and maintenance of products: optical fiber transmission, need not to adjust the optical path.
